Solar inverters Huawei 50 kW – FUSIONSOLAR SUN2000-50KTL-M3
The Huawei 50 kW inverter – FUSIONSOLAR SUN2000-50KTL-M3 is a solar energy conversion device designed to convert DC power generated by commercial and industrial photovoltaic systems into AC power. This inverter has a nominal power output of 50 kW and is equipped with advanced technology to ensure high efficiency and reliable performance. Additionally, the Huawei 50 kW inverter – FUSIONSOLAR SUN2000-50KTL-M3 is designed to be easy to install and operate.
Key features of this inverter include:
Higher yields – Up to 30% more energy with Optimizer
Active safety – Active protection against electric shock monitored by artificial intelligence AI
Flexible communication – WLAN, Fast Ethernet, 4G communication accepted
- High efficiency: This inverter uses advanced technology to ensure high efficiency in converting DC power to AC power.
- Reliable performance: The Huawei FUSIONSOLAR SUN2000-50KTL-M3 inverter is designed to provide reliable performance over a long period of time.
- Easy to install and operate: The inverter is designed to be easy to install and operate, with a user-friendly interface and flexible communication options.
- Active safety: The inverter comes with active protection against electric shock, which is monitored by artificial intelligence.
- Higher yields: With the use of Optimizer, this inverter can provide up to 30% more energy.
- Maximum DC voltage: 1100 V
- Maximum AC apparent power: 55,000 VA
- 4 MPPTs for versatile adaptations to different aspects
- Intelligent monitoring with 8 strings and fast troubleshooting
- Maximum efficiency of 98.7%, with a European efficiency of 98.4%
- 24/7 support
- Arc protection
- Easy installation
- High efficiency
- IP protection
- MBUS
- Low maintenance
- Reliability
- Remote control
- Warranty
INPUT
Maximum input voltage
1.100 V
Maximum current per MPPT
30 A (per MPPT) / 20 A (per phase)
Maximum short-circuit current per MPPT
40 A
Startup voltage:
200 V
MPPT operating voltage range:
200 V ~ 1.000 V
Nominal input voltage:
600 V
Number of inputs
8
Number of MPP trackers:
4
European efficiency
98,0%
COMMUNICATION
- LED display indicators, Bluetooth + APP
- RS485: Yes
- Smart Dongle WLAN/Ethernet via Smart Dongle-WLAN-FE (optional)
- 4G/3G/2G via Smart Dongle-4G (optional)
- Monitoring BUS (MBUS): Yes (an isolation transformer is required)
Standards for grid connection
IEC 61727, VDE-AR-N4105, VDE 4110, VDE 0126-1-1, BDEW, G59/3, UTE C 15-712-1, CEI 0-16, CEI 0-21, RD 661, RD 1699, P.O. 12.3, RD 413, EN-50438-Turkey, EN-50438-Ireland, C10/11, MEA, Resolution no.7, NRS 097-2-1, DEWA.
OUTPUT
Nominal AC power output
50.000 W
Max. Apparent AC power output
55.000 VA
Max. AC active power output (cosφ=1)
55.000 W
Nominal output voltage
400 Vac / 480 Vac, 3W+(N) + PE
Nominal AC grid frequency
50 Hz / 60 Hz
Nominal output current
72,2 A la 400 Vca, 60,1 A la 480 Vca
Max. output current
79,8 A la 400 Vca, 66,5 A la 480 Vca
Adjustable power factor range
0,8 LG 0,8 LD
Max. total harmonic distortion
<3%
GENERAL INFO
- Dimensions (L x W x H): 640 x 530 x 270 mm (25.2 x 20.9 x 10.6 inches)
- Weight (with mounting plate): 49 kg (108.1 lbs)
- Operating temperature range: -25°C ~ 60°C (-13°F ~ 140°F)
- Cooling method: Intelligent air-cooling
- Max. operating altitude: 4,000 m (13,123 ft)
- Relative humidity: 0% RH ~ 100% RH
- DC Connector: Amphenol Helios H4
- AC Connector: Waterproof connector + OT/DT terminal
- IP Protection Rating: IP 66
- Transformerless topology
- Night-time power consumption: ≤ 5.5 W
Solar inverters Huawei 50 kW – FUSIONSOLAR SUN2000-50KTL-M3
The Huawei 50 kW - FUSIONSOLAR SUN2000-50KTL-M3 inverter is a solar energy conversion device designed for use in commercial and industrial photovoltaic systems. With a nominal power output of 50 kW and advanced technology, this inverter delivers high efficiency and reliable performance.
Featuring maximum power point tracking (MPPT) technology, the Huawei 50 kW - FUSIONSOLAR SUN2000-50KTL-M3 inverter ensures maximum efficiency in converting solar energy into electrical power. The inverter also includes active cooling technology for optimal temperature control and extended component lifespan.
Compatible with a wide range of solar panels, the Huawei 50 kW - FUSIONSOLAR SUN2000-50KTL-M3 inverter connects to solar modules via input terminals.
A 7-inch color touch LCD screen allows users to view and adjust system settings, while built-in monitoring and diagnostic functions enable quick detection and resolution of issues.
Equipped with a range of protective features, such as overvoltage protection, high-temperature protection, and short-circuit protection, the Huawei 50 kW - FUSIONSOLAR SUN2000-50KTL-M3 inverter is designed for safety and reliability.
Overall, the Huawei 50 kW - FUSIONSOLAR SUN2000-50KTL-M3 inverter is an excellent choice for business owners and system operators seeking a highly efficient and reliable photovoltaic system.
